The 44 S&W Magnum
The new gun employs the heavy N frame regularly made for the 357 Magnum, 38/44 Heavy Duty, 44 Special and 45 Smith & Wessons, but this gun has all major parts made from a premium lot of special alloy steel, perfectly heat treated for greatest strength in the Smith & Wesson furnaces. The hammer and trigger are case hardened to a new high in this treatment, insuring a perfect and lasting, crisp, clean trigger pull. The heavy barrels are 6½” or 4″ in length with a wide rib and encased ejector rod. The top of frame and barrel are grooved along the rib and sandblasted to prevent glare and reflection.
All lockwork parts and bearing surfaces are honed to a mirror finish to insure a maximum smoothness, either single or double action. The hammer has a wide target spur and the trigger has a wide flare that perfectly contours the trigger finger for easy cocking and maximum contact area of finger to trigger. The trigger pull runs from three to four pounds, and is as clean and sharp as breaking glass.
The S. & W. rear sight, fully adjustable for both elevation and windage and of locking micrometer-construction, has a white-outlined rear notch of adequate width to insure a strip of light on each side of the front sight, a one-eighth inch red-insert ramp, when held at arms length. The red-insert ramp front shows up well on a black target or game in any shooting light. Stock straps are grooved to prevent slippage. Stocks, of Goncalo Alves fancy figured hardwood, are of the S. & W. Target shape and offer a filler behind the trigger guard as well as covering the front strap and the butt of the gun.
They are hand filling and the left stock is hollowed out for the right thumb. They are perfectly shaped to fit and fill the hand and distribute the recoil over as wide a surface as possible. They are also finely and attractively checkered. The big gun weighs 47 ounces empty. Main spring is the standard S. & W. long spring with compression screw in front strap. Cylinder and barrel clearance are held to a minimum, yet the gun has the smoothest possible action. Cylinder locks tight and lines up perfectly. The cylinder is a full 1.75″ long and has ample room for my 250 grain bullet reloaded in the one-eighth-inch longer 44 Magnum case, still leaving a sixteenth of an inch clearance when the bullet is crimped in the regular crimping groove.
